Tool Grinding Fluids

Tool manufacturing is an important part of metalworking Industry. Machine tools and grinding wheel technologies have progressed continuously in the tool grinding process with an objective to improve on grinding parameters like grinding speeds, higher feed rates, better surface finish etc.

Advanced Grinding Fluids : The Right Balance of Lubrication, Cooling and Flushing

The grinding oil must follow this evolution by providing the right balance between cutting and lubrication. A frequent problem with “regular grinding oils” is its focus on over lubricating the work area. These regular grinding oils with high viscosity reduces the grinding wheel’s cleaning ability and as a result the grinding wheel does not cut enough.

Tool grinding process generates a lot of heat. The gradual rise in temperature between the workpiece and the wheel leads to microcracks in the tool, grinding burns and reduce the grinding efficacy of wheel. The tool grinding fluid should provide optimal lubrication to reduce frictional heat, clean the chip out of machining area, enable higher grinding speeds and metal removal, provide cooling to avoid thermal damage to the grinding tool and workpiece.

Cobalt Leaching While Carbide Grinding

Another critical aspect that comes into play while grinding carbide material is release of cobalt into cutting fluid (here grinding fluid) known as cobalt leaching. The cobalt leaching process is initiated by chemical or electrochemical reaction between the carbide surfaces and environment. Loss of cobalt leads to weakening of carbide structure and further accelerating the leaching process. Cobalt is toxic, to inhibit leaching it is important that cutting fluid provides quick heat dissipation and contains the additives that are required to deter the cobalt leaching process.

Recommended by leading tool and machine manufacturers, Bechem’s range of grinding fluids are specially formulated for grinding of carbide, high speed steel and other difficult to grind materials. The tool grinding fluids provide optimal lubricity and cooling with good flushing property to ensure hassle free grinding.

Benefits with BECHEM’s Tool Grinding Fluids

Ensures excellent surface finish
Enables higher grinding speed and material removal rate
Prevents cobalt leaching
Possesses good flushing property
- Ensures longer wheel life and clean machines

Ensures safer work environment at the shop floor
- Low misting and
- Has high flash point
Good filterability
- Can be filtered through very fine filtering media as well
Provides long sump life and low top ups

BECHEM's range of tool grinding fluids

Berugrind 7 HC

Non water miscible fluid based on high quality mineral oil for the right balance of cutting and cooling performance. Berugrind 7 HC has low evaporation tendency. Possesses high dirt carrying capacity. Has good flushing properties. Ensures minimal foam formation. Recommended for grinding of tungsten carbide tools, honing, engraving, mould construction, die manufacturing processes.

Berugrind 7 HC	Grinding Extended tool life Low residue level Honing Good rinsing performance Low foaming Chlorine-free
Viscosity at 40 °C [mm2/s]	7 – 9
Flash point [°C]	≥ 160
Materials to be processed	Carbides, Steel, Cast steel, Stainless steel, Titanium

Berucut XC 1010

Developed on fully synthetic base oil with superior anti wear properties . Provides excellent surface finish along with good corrosion protection. Minimises foam formation. Free of Chorine and Heavy metals. Specially designed for increasing productivity and ensure extended tool life. AW / EP additives ensure high load-bearing capacity and reduce wear on the tool. Supports high cutting speeds

Recommended for machining processes such as Turning, Milling, Deep drilling, thread cutting and tooth grinding.

Berucut XC 1010	Chlorine-free Extended tool life Good rinsing performance High load Corrosion protection
Viscosity at 40 °C [mm2/s]	11-14′
Flash point [°C]	≥ 179
Materials to be processed	Steel, Titanium, Nickel alloys, Stainless Steel

Send Your Queries

Connect with us for more information on product samples, technical comparisons and details on pack sizes. Contact Us

Our Expertise

BECHEM Avantin range are the most advanced breed of cutting fluids that have set new benchmarks in the industry by achieving maximum performance with minimal consumption. Fortified with advanced additives the BECHEM Avantin range contend harsh external impurities such as hydraulic oil, swarf and grinding dust whilst delivering unmatched performance.

BECHEM’s MQL range of advanced lubricants form a continuous film on the tool and metal job interface with the intention of reducing friction and thereby temperature build up. Berucut and Beruform range of MQL lubricants possess excellent lubricity as well as good flushing properties.

Beruclean range of industrial cleaners provide spotless and speck free components, leaving no residues on the component for further machining processes. The Beruclean range is available in both aqueous and solvent-based biodegradable variations for wide variety of materials

Related Case Study

Experience ease of cutting hard tools with tool grinding fluids by Bechem

Grinding of hard metals generates a lot of heat between the grinding wheel and work piece interface. Mist formation, consumption of cutting fluid and grinding wheel life are parameters that often vary drastically.

A trial with Berugrind 7 HC, a neat cutting oil with special additives from BECHEM, unraveled possibilities for the production team to ensure seamless grinding with superior job finish.
