Berusynth range of synthetic chain oils are based on proven synthetics including Esters, Polyalphaolefin (PAO) and Polyglycols. These synthetic chain oils have good ‘Viscosity Index’ characteristics enabling them to operate in a wide operating temperature range (-40°C to +250°C). Berusynth series have minimal evaporation rate even at extreme high temperatures. Polarity within Berusynth Chain oil series ensures good tackiness and creeping properties much required for effective lubrication of chain application. Maintaining a tacky lubricating film, Berusynth series avoid unnecessary spillage from chain ‘I links’ to the component or on the shop floor.
Berusynth Chain oil series is recommended for long term lubrication of heavy duty chains that experience heavy loads, extreme operating temperatures as well as for meeting special requirements such as processing industries. The advanced formulation with special polymer additives offer excellent lubricity for friction partners in boundary and mixed friction zones. The chain oil series by BECHEM leaves minimum residue after active operational life, thereby helping in easier cleaning of chain links.
BECHEM’s Range of Synthetic Chain Oils
Synthetic high performance, adhesive chain oil with excellent wetting and penetrating properties. Highly adhesive property of the oil ensures minimal drop-off. Berusynth CU 250 provides high resistance against hot and cold water wash-off and also provides outstanding protection against corrosion of friction partners. CU 250 has low evaporation rate even when subjected to high temperatures and leaves no residue after active life. Berusynth CU 250 is NSF H2 certified. Also available in spray form, known as Berusynth CU 250 Spray.
Applications: Recommended for conveyor chains in stenters and drying frames in the textile industry. Also recommended for conveyor chains in paint shops, drying ovens, machines in printing industry , shrink tunnels, lift chains in high-level rack storage facilities. Other applications include conveyor chains in stone wool and glass wool production, dipped latex rubber gloves etc.
|Product||Base Oil||Viscosity at [40 °C mm2/s]||Flash point °C||Send Your Queries|
|Berusynth CU 250||Ester||250||≥ 250|
Synthetic high temperature chain oil for superior lubrication film with high load carrying capacity and provides excellent protection against wear of contacting surfaces. The high performance oil has low evaporation rate even at high temperatures. Berusynth CB 180 H1 has good penetration properties and high wash-out resistance. Berusynth CB 180 H1 is NSF H1 approved as well as Halal and Kosher certified. Resistant to hot and water and provides excellent protection against corrosion.
Applications: Recommended for conveyor chains in baking, drying ovens of food processing and beverage industry. Suitable for chains used in the production of surgery rubber gloves.
|Product||Base Oil||Viscosity at [40 °C mm2/s]||Flash point °C||Send Your Queries|
|Berusynth CB 180 H1||Ester||180||≥ 240|
Frequently Asked Questions
Short bytes for queries on lubricants that always bothered you
Keeping a tab on oil health through oil analysis is a great proactive practice. It helps to check for contaminants and machine wear. Abnormal analysis result indicates potential danger in the system. Oil analysis helps in identifying root cause and take corrective measures immediately. Issues such as metal wear, broken seals, improper filtration pose greater threat to machine and can lead to extended and expensive downtime.
Regular oil analysis enables finding the right lubricating interval and increases the life of equipment. It also enhances productivity by reducing unplanned downtime resulting in smoother business operations.
Environment in which the lubricant is stored plays a crucial role in lubricant performance. Lubricants stored for long under extreme environmental conditions such as high temperatures, higher temperature variations, severe humidity and corrosive environments can affect the lubricant performance based on the product category.
Oils stored improperly beyond storage life established by the supplier, can have issues such as oxidation, sedimentation build up and moisture absorption. For greases, oil separation from the grease would be the primary concern.
Ambient temperature, clean and dry atmosphere can ensure maximum storage life of a lubricant. A consultation with the lubricant manufacturer on the shelf life of the lubricant is recommended to ensure quality.
Emulsifiers help in increasing solubility of the cutting oil in water by breaking down the oil into smaller globules and thereby maintaining a stable and uniform emulsion. A stable emulsion provides longer tank life and also ensures lower carry over loss resulting in minimum top ups.
The basic function of a cutting fluid is to provide adequate lubrication to the tool and work piece friction zone as well as remove heat generated by cooling the deformation area. Some additional properties that are desired in the cutting fluid are,
- Ability to rinse away the metal debris from the friction zone
- Provide adequate protection against corrosion to the machine and work piece
- Compatible to machine paint and ensure stain free machines
- Easy to handle and comply to safety and environmental regulations
Intense amount of heat is generated between the grinding wheel and work piece due to friction and cutting process. Uncontrolled heat can lead to structural damage of the work piece and increase in wear rate of the wheel. Fine dust and metal debris are continuously generated and needs to be cleared out from the wheel, work piece interface. The cutting fluid for Grinding process should possess the right amount of lubricity and cooling property to reduce friction and manage temperature rise. Additionally the cutting fluid should also possess the right amount of detergency and flushing property to clear the fine machined debris.
With a higher dosage of lubricity to reduce friction and temperature rise, the coolant should also contain EP additives that can protect the tool by forming a thin layer between the tool and work piece. Additionally, the cutting fluid should possess the right amount of flushing property to clear the machined swarf from the machined area
Ideally, de mineralized (DM) water with neutral pH of 7 and hardness less than 50 ppm is recommended. The chloride level should be less than 25 ppm with no bacterial and fungal presence. Usage of hard water leads to increased conductivity, hence poor rust protection and lower sump life.
‘Oil into water’ or ‘oil in last (OIL)’ is a recommended practice for better solubility of the coolant in water. Water in oil would result in large size oil globules with the oil loving ‘oleopphilic’ ions of the emulsifier being ineffective. This would lead to a unstable oil water emulsion.
- Keep a regular check on the concentration of the emulsion, maintain recommended concentration
- Remove any tramp oil from the coolant tank thoroughly
- Measure pH regularly
- Avoid all sorts of dust near the tank, remove the machined debris from the tank regularly.
- Follow the prescribed procedure while changing the coolant.
Including the effectiveness of ‘cutting fluid’, tool life is impacted by a host of other parameters including cutting speed, feed rate, depth of cut, tool and work material, nature of cut and machine rigidity. Cutting fluids with high amount of EP additives would insulate the tool from frictional wear and ensure longer life. Studies have shown that with all other parameters remaining the same, cutting fluids with good EP properties can increase tool life by 20 to 40%.
Aluminum alloys which contain Copper and Zinc as alloying elements are susceptible to chemical reaction (black stains) with cutting fluids that contain Amines as ingredient. For machining such Aluminum alloys, amine free cutting fluids are recommended
Colour change of the emulsion is notable during machining of Cast Iron with the Fe ions dissolving with the emulsion. However with all other parameters such as pH, conductivity, concentration and microbial behavior remaining within the specified limits, colour change does not impact performance of the emulsion.
Operators handling components with bare hands and in constant touch with the emulsion could feel irritation and itchiness or develop rashes as well. As sensitivity of the skin is subjective, operators need to handle machined components with proper gloves and other protective gear with the objective of avoiding direct contact with the emulsion. Barrier creams could also be considered where direct contact is unavoidable.
Ensuring a stable emulsion with regular check on pH levels and microbial growth by removing chips, swarf and tramp oil from the tank will also help in reducing possibilities of such concerns. Encourage operators to maintain good personal hygiene, recommend regular laundry of their work dress, avoiding wet rags into pockets, usage of mild soaps etc.
