Cold Forming Oils

Extreme surface pressure between tool and work piece require high performance parting agents which are able to build up pressure resistant layers during the cold forming process such as punching and blanking in order to prevent premature wear, fretting or even breakage of the tools.

BECHEM’s range of cold forming oils have been developed after thoroughly understanding requirements of the customer and subsequently collaborating with machine manufacturers for superior product function. Berudraw and Beruform range of speciality fluids by BECHEM for punching and blanking operations are cost efficient, eco friendly and provide superior surface finish.

BECHEM’s range of cold forming oils

Beruform MF 155 I

Non water miscible multifunctional oil for Cold massive forming on multiple stage presses. Suitable for cold extrusion, piercing, punching, blanking and drawing etc. Extends tool life. Extremely resistant to ageing. Provides good corrosion protection

Beruform MF 155 I	Honing Extended tool life Corrosion protection Chlorfrei_50.png
Kin. Viscosity at 40 C (mm2/S)	99 – 121
Flash Point [°C]	≧ 180
Materials to be processed	Steel, Stainless Steel, Aluminium, Copper and Brass

Beruform MF 155 C

Non water miscible forming oil recommended for cold extrusion, sheet forming, piercing, punching, blanking and drawing etc. Cold drawing of bare steel in wet drawing processes, forming degrees between 20% and 30% can be achieved. Drawing of round bars and profiles (square, hexagon) with difficult geometries.

Beruform MF 155 C	Deep Drawing Punching Fine Blanking Bending Extended tool life
Kin. Viscosity at 40 °C (mm2/S)	88 – 108
Flash Point [°C]	≥ 190
Materials to be processed	Steel, Stainless Steel, Aluminium, Copper and Brass

Berudraw 4046

Non water miscible oil for drawing of round bars and profiles (square, hexagon) with difficult geometries. Recommended for deep drawing as well as demanding sheet forming and cold forming operations.

Berudraw 4046	Minimum quantity lubrication Fine blanking Wire drawing Bending Deep drawing Low residue level Chlorine-free Extended tool life
Viscosity [mm2/S] at 40 °C	277 – 337
Flash Point [°C]	≥ 186
Materials to be processed	Steel, Stainless steel

Beruform KFP 96

Non water miscible cold forming oil for demanding and multiple forming operations. Suitable for cold extrusion, piercing, punching and deep drawing operations. Provides longer coolant service life. Free of Chlorine and heavy duty metals.

Beruform KFP 96	Minimum quantity lubrication Fine blanking Wire drawing Bending Deep drawing Low residue level Chlorine-free Extended tool life Cold forming
Viscosity [mm2/S] at 40 °C	81.5 – 100.5
Flash Point [°C]	≥ 170
Materials to be processed	Steel, Stainless steel

Beruform STO 110

Recommended for punching, bending and stamping operations. High-performance, fully synthetic forming oil for minimum quantity lubrication with higher flash point. Can be applied by spray equipment, drip oiler, roller or brush

Beruform STO 110	Minimum quantity lubrication Fine blanking Deep drawing Bending Low residue Chlorine-free
Viscosity [mm2/S] at 40 °C	41.4 – 50.6
Flash point [°C]	≥ 290
Materials to be processed	Steel, Stainless steel, Aluminium, Copper

Beruform STO 5

Non water miscible oil for easy to medium machining operations such as punching, cutting and bending. Free of chlorine and heavy metals. Provides excellent surface finish. Can be applied by spray equipment, drip oiler, roller or brush.

Beruform STO 5	Minimum quantity lubrication Fine blanking Deep drawing Bending Low residue Chlorine-free
Viscosity [mm2/S] at 40 °C	4.7
Flash point [°C]	≥ 160
Materials to be processed	Steel, Stainless steel, Aluminium, Copper

Beruform VSM 9

Biodegradable punching and bending oil. Recommended for operations of fine sheets upto 1mm approx. Also for forming of electrical contacts.

Beruform VSM 9	Fine blanking Bending Low residue level Safe working environment Food grade / Pharmaceutical technology Biodegradable
Viscosity [mm2/S] at 40 °C	1.3
Flash Point [°C]	≥ 65
Materials to be processed	Steel, Aluminium, Copper and alloys

Beruform 148-68 I

High performance multifunctional oil for demanding forming processes such as multi stage presses in cold forming processes. Suitable for cold extrusion, piercing, punching, blanking and drawing etc. Extends tool life. Provides excellent forming performance. Provides good corrosion protection.

Beruform 148-68 I	Honing Extended tool life Corrosion protection Chlorfrei_50.png
Kin. Viscosity at 40 C (mm2/S)	61-75
Flash Point [°C]	≧ 190
Materials to be processed	Steel, Aluminium, Copper and Brass
